Description
Product Information
SKU725408
Mfr Part#CA-1J1-00S1NN00
UPC841163001059
General
Series:Versa H17
General Specifications
Case Type:Mini Tower
Color:Black
Material:Steel
Bezel Material:Steel
Max Motherboard Size:microATX
Motherboard Support:microATX
Mini-ITX
Motherboard Tray:Fixed
Side Panel:Solid
Cable Routing Holes:Yes
Buttons:Power
Expansion
Internal 3.5" Drive Bays:2
Internal 2.5" Drive Bays:2
Expansion Slots:4
Ports & Connectors
Front Ports:1 x Audio Out
2 x USB 2.0
1 x Audio In
1 x USB 3.2 Gen 1 Type-A
USB 2.0:2
USB 3.0:1
Audio Ports:Audio In Jack
Audio Out Jack
Cooling Specifications
Radiator Mounting:Front Internal
Rear Internal
Supported Radiator Sizes:1 x 120 mm Front Internal
1 x 240 mm Front Internal
1 x 280 mm Front Internal
1 x 120 mm Rear Internal
1 x 140 mm Front Internal
Liquid Cooling Ready:Yes
Fan Bays:1 x Rear 120mm Fan Bay
1 x Top 120mm Fan Bay
1 x Top 140mm Fan Bay
3 x Front 120mm Fan Bays
Case Fans Exhaust:(1) Rear 120mm Fan
Included Fans:1 x 120mm Fan
Power Supply
Power Supply:Not Included
Power Supply Mount:Bottom (ATX)
Package Contents
What's in the Box:Computer Case, 120mm Fan, Product Manual
Physical Specifications
Width:8.10 in. (205.00 mm)
Depth:15.00 in. (381.00 mm)
Height:15.40 in. (390.00 mm)
Weight:9.92 lbs. (4.50 kg)
Max CPU Heatsink Height:6.10 in. (155.00 mm)
Max Power Supply Depth:8.66 in. (220.00 mm)
Max Video Card Length:13.78 in. (350.00 mm)
Box Dimensions (WxDxH):19.20 x 17.70 x 10.30 in. (487.68 x 449.58 x 261.62 mm)
Warranty
Parts:3 Years
Labor:3 Years
