Description
Product Information
SKU618306
Mfr Part#TE100-S5
UPC710931204179
Specifications
Status Indicators:Power
Link/Activity
100M
Memory Buffer:256 KB
Network Management:Unmanaged
Rack Mountable:No
Stackable:No
Type:Switch
MAC Address Table:1K MAC Address Table
Jumbo Frames:None
Layer:Layer 2
Data Transfer Rates
Half-Duplex Data Transfer Rate:10/100Mbps
Network Speeds:20/200Mbps
Compliant Standards (Wired):IEEE 802.3 i/u/x
Connector Type:RJ-45
Switching Method
Switching Protocol:Ethernet
Switching Method:Store-and-Forward
Switch Bandwidth:1.2 Gbps
Ports & Connectors
Port Types:LAN
Network Ports and Connectors:5 x RJ-45 10/100
Power
Power Supply:AC Adapter
Physical Specifications
Depth:3.00 in. (76.20 mm)
Height:1.20 in. (30.48 mm)
Operating Temperature Range:32 – 122 F (0 – 50 C)
Width:3.90 in. (99.06 mm)
Weight:4.50 oz. (127.57 g)
Operating Humidity Range:10% – 90% Non Condensing
Warranty
Parts:Lifetime Limited
Labor:Lifetime Limited
Package Contents
What's in the Box:TE100-S5 Switch, Multi-Language Quick Installation Guide, Power Adapter
